CONTROL PANELS
ACCESSORIES
GSM/GPRS & IP Communication
PowerMax® Control Panels
Visonic's broad offering of PowerMax wireless home security systems answers varying needs and budgets. The control panels can be connected to a wide range of PowerCode wireless peripherals, providing outstanding installation flexibility and ease of use.
PowerMaster-30 G2
PowerMaster-30 G2
PowerG Professional Wireless Intrusion Alarm System
PowerMaster®-30 G2 is a professional wireless security, safety and control system. Suitable for advanced applications and heavy duty operation, it has a superior range, prolonged battery life and unmatched wireless robustness. Moreover, it provides outstanding wireless functionality with all peripherals.
PowerMaster-30 G2 fully answers the most demanding requirements facing the security industry today, as well as the challenges of tomorrow.
About PowerG® Wireless Technology
PowerG combines several field-proven, advanced wireless technologies, like those used in cellular networks and Bluetooth, with the highly reliable AES encryption method. The greatest innovation in PowerG is having these technologies operate on non-rechargeable batteries while still keeping all devices connected and online. When used in residential or commercial security alarm systems, this combination of technologies delivers the unmatched reliability, robustness and transmission range we have come to expect from modern wireless applications – this time on batteries. In addition, PowerG provides numerous advantages for professional installers, central monitoring stations and end-users alike.
PowerMaster-30 G2 Features:
Unmatched affordability and performance
Accommodates over 120 wireless devices:
Up to 64 zones
Up to 32 keypads
Up to 32 keyfobs
Up to 8 sirens
Up to 4 repeaters
48 user codes
Supports partitions
Up to 2 wired zones, 1 wired siren and 1 programmable output
Built-in PSTN dialer
Optional GSM/GPRS and ADSL internal modules
Stores 1000 log entries
Optional proximity reader
Remote voice box
Extensive range of PowerG peripherals for every application
PowerMaster-10 G3
PowerMaster-10 G2
PowerG Compact Two-way Wireless Intrusion Alarm System
PowerMaster-10® G2 introduces a new era in intrusion alarm systems, literally redefining wireless home security and reliability. It is Visonic's first wireless intrusion alarm system whose control panel uses the revolutionary PowerG wireless technology .
About PowerG® Wireless Technology
PowerG combines several field-proven, advanced wireless technologies, like those used in cellular networks and Bluetooth, with the highly reliable AES encryption method. The greatest innovation in PowerG is having these technologies operate on non-rechargeable batteries while still keeping all devices connected and online. When used in residential or commercial security alarm systems, this combination of technologies delivers the unmatched reliability, robustness and transmission range we have come to expect from modern wireless applications – this time on batteries. In addition, PowerG provides numerous advantages for professional installers, central monitoring stations and end-users alike.
PowerMaster-10 G2 Features:
Two-way communication ensures there are no lost alarms
Transmission range is far greater than the industry standard enabling repeater-free installations even in large premises*
Extended battery life in almost all PowerG peripherals – between 4-8 years for typical use All devices are configured from the panel – no hardware switches and no need to re-open the peripherals once closed
Visible signal quality indication shown on the device enables the installer to choose the optimal location without having to walk to the panel during mounting
Customized configuration templates enable configuration of the devices collectively instead of individually
Diagnostic tool indicates RF link quality based on the previous 24 hours’ statistics, immediately displaying problems and enabling installation verification
Powerful tools for central monitoring stations such as remote control of all peripherals, remote walk tests and measurements of link quality of all wireless connections in the connected premises
Multiple frequency channels (up to 50) using Frequency Hopping Spread Spectrum (FHSS) technology overcome interference to wireless communication
Communication is protected by the proven AES-128 encryption algorithm to protect against sophisticated intruders, "code grabbing" and message substitution
Link Message collisions are eliminated with TDMA synchronized communication technology similar to WiMAX, GSM and Bluetooth to TDMA in the glossary
Devices dynamically optimize their route to the control panel using available repeaters according to changes in the environment
*Measured line-of-site transmission range: 2000m/6500ft @ 8m/24ft,
750m/2500ft @ 2m/6.5ft
PowerMaxPro
PowerMaxPro
Advanced Home Security for the Broadband Era
The Powermax Pro is available in a range of colours such as White, Alluminium & Black.
PowerMax®Pro is an all-in-one wireless home security system that brings an entirely new level of versatility, connectivity and style to the world of home security. It lets homeowners view and control their homes from anywhere via any web browser or mobile phone, delivering ease of use and reliability, in an elegant, contemporary design.
The PowerMaxPro's intelligent, professional grade architecture delivers exceptionally robust performance, starting with a fast and easy installation and setup. With its built-in PSTN communicator and X-10 home control interface, and the ability to add internal GSM/GPRS or Broadband IP communications modules, it offers users and installers outstanding flexibility: homeowners can select the home security system that matches their requirements and budget; and service providers gain the perfect platform for offering web-based security solutions.
Adding the unique internal PowerLink module turns PowerMaxPro into a fully managed web-based security and home control solution. This solution includes real-time camera surveillance and home control, alarm time image verification, mobile phone and email event notifications, and much more. Homeowners can be logged in to the system via any web browser.
Breeze through installation using intuitive menus and voice prompts. Reduce training time and customer support with the icon-based keypad and audio/visual system status notifications.
PowerMaxPro Features:
High-end, modular design
Self contained; no need for external boxes
Multiple optional built-in modules:
Internal PowerLink module enables camera connectivity for real-time viewing and system operation
Internal GSM/GPRS communicator
Internal Broadband IP communicator
Internal RFID (proximity tag) reader
External voice box
Integral X-10 interface for home management – alarms, lights, home appliances control.
Supports up to 3 partitions and multiple common areas (Optional)
Event reporting to: monitoring stations, pagers, SMS messages, e-mail, web applications, mobile phones, landline phones
Two-way PowerCode™ RF system with diversity antenna enables support for Visonic's two-way sirens and two-way keyfobs for instant feedback from the system Internal or external power supply
Elder care application
LCD-based user interface
28 wireless zones with additional 2 hardwired ports, 1 12v hardwired siren port and 1 PGM port for full coverage of connectivity options
Up to 72 hours battery backup
Supports 8 user codes
Full compliance with most international standards including FCC, EN50131 Grade 2 and more
PowerMaxComplete
PowerMaxComplete
All-in-one Professional Grade Wireless Security
PowerMax®Complete is a professional-grade wireless security and personal safety solution especially designed to answer the needs of residential and small office customers, many of whom are disconnecting from the standard PSTN network.
PowerMaxComplete packs the full range of communication, configuration and expansion options into a single, modular and cost-effective wireless panel. The built-in internal PSTN communicator and easy-to-add modules make the PowerMaxComplete perfectly compatible with the varied needs and budgets of a variety of customers.
The ability to add internal GSM/GPRS and/or Broadband IP* communication modules ensures maximum reliability in the delivery of events to the alarm central station by facilitating internal redundancy of GPRS, GSM and SMS. These additional communication modules can also be used as the primary communication or as a backup for PSTN in the event of network failure or line sabotage during a burglary attempt.
PowerMaxComplete's professional architecture ensures fast and simple installation and easy operation. It has an easy-view LCD display and icon-based keypad for intuitive programming, a main unit construction enabling installers to enroll and test peripheral functionality while the bracket is attached to the wall, and much more. This, together with features such as PCB board protection from accidents or sabotage and the option of adding an internal fully-protected power supply, create the ultimate combination of high reliability and ease-of-use.
PowerMaxComplete Features:
• Versatile communications capabilities:
Built-in PSTN communicator.
Easy-to-add internal GSM/GPRS and/or IP* communications modules for maximum alarm reporting reliability to the central station and back-up for the standard PSTN lines.
• Voice functionality option (at the manufacturing level): two-way voice communication, voice prompts and family message center.
• Optional proximity reader enables rapid arming and disarming without the need for a keyfob.
• Expander module for adding 1 PGM output, 2 additional hardwired zones, 1 wired siren output, and Speech Box interface.
• Choice of external or internal (fully protected) power supply.
• Two-way RF system with diversity antenna facilitates highly reliable radio communication.
• Supports up to 3 partitions and multiple common areas (Optional).
• Easy-view LCD display and icon-based keypad.
• Back-up battery – supplies multiple peripherals and also backs up internal
GSM/GPRS/IP modules.
• Full compliance with most international standards and regulations, including: FCC, CE and EN50131 grade 2.
* All add-on communications modules need to be purchased separately. The IP module is expected to become available during 2010
PowerMaxExpress
PowerMaxExpress
Ultra-compact Wireless Security with Internal Communications Options
PowerMax®Express is a wireless home security solution that includes all the reliability and features that homeowners and professional installers require. Packing outstanding functionality into an exceptionally small, wireless control panel, the PowerMaxExpress provides the ideal combination of functionality and affordability, and gives installers the versatility to offer a home security solution that meets the needs and budgets of the broadest range of customers.
Unique among its size class, this small, self-contained panel has a standard built-in PSTN communicator and offers the flexibility to add internal GSM/GPRS and Broadband* communications modules. The solution can be further extended with a wide range of accessories to provide a comprehensive home security solution that offers a high level of safety and home control.
With its compact and streamlined design, the PowerMaxExpress control panel is nearly invisible on the wall and fits into any modern décor. In addition, operation, enrollment and programming are intuitive with an easy-view LCD display and icon-based keypad.
PowerMaxExpress is compliant with most international standards and offers maximum reliability and performance. Advanced security features include PCB board protection from accidents or sabotage, output protection from short circuits and current surges, and a two-way communication system with a diversity antenna to facilitate highly-reliable radio transmissions.
PowerMaxExpress Features:
All-in-one, self-contained panel
Stylish, ultra-compact design, fits any décor
Versatile communications capabilities:
Built-in PSTN communicator
Easy-to-add internal GSM/GPRS and/or Broadband* communications modules for maximum alarm reporting reliability to the central station and back-up for the standard PSTN lines
Simple installation and user-friendly operation with intuitive icon based keypad Market leading range of wireless peripherals Two-way RF system with diversity antenna
Designed to comply with most international standards and regulations, including: FCC, CE and EN50131 grade 2
* All optional communication modules need to be purchased separately
PowerMax+
PowerMax+
Advanced Home Security and Management System
PowerMax®+ is an advanced home security and automation system that enables users to verify the status of their property by viewing real-time images of their homes from any remote location. This is complemented by a host of powerful capabilities: detection of smoke, gas and flooding, reliable full GSM backup capabilities, easy remote access via SMS, e-mail, mobile or regular phone or a secure web application, and much more. PowerMax+ offers easy yet flexible configuration and clean wireless installation.
PowerMax+ enables homeowners to verify the status of the system, reprogram security functions, and even control their home appliances and lighting – anywhere and any time. From work, on vacation, or even during travel, homeowners easily access the system via SMS, e-mail, mobile and regular phones, or a secure web application. Other important management capabilities include an advanced scheduler for automation of multiple daily routines, and a voice message center accessible from within and outside the home.
PowerMax+ offers all the unsurpassed reliability and proven performance that have made PowerMax the choice of installers, homeowners, monitoring companies and national utilities. Hundreds of thousands of families in more than 80 countries rely on Visonic PowerMax systems to protect their homes.
PowerMax+ Features:
Remote home management – alarms, lights, appliances, A/C – via telephony, cellular or Internet connections
Optional GSM-based backup communication channel – for uninterrupted connectivity even in case of tampering with the system
Fast and easy installation; easy and convenient programming options
Complete home control solution – provides status updates and controls up to 15 electrical devices
Detectors supported: PIR and pet-immune motion detectors; glass-break, flood, smoke and gas detectors; door/window magnetic contact, and more
Event reporting to: monitoring stations, pagers, SMS messages, e-mail, web applications, mobile phones and regular phones
Family message center with standard and remote access for voice recording/playback
Remotely initiated hands-free two-way voice communication
Latchkey mode informs parents of a child’s arrival to the home
Intuitive textual and audible user interface with language adaptation
Full compliance with international standards and regulations
AmberSelect
AmberSelectAdvanced Personal Emergency Response, Safety and Lifestyle Management Solution
Amber®Select combines personal emergency response with lifestyle, safety and well-being management in a single, comprehensive, and attractive solution. The AmberSelect is an ideal solution for seniors and others with evolving healthcare concerns who wish to continue living independently in their own homes.
With its sleekly designed, easy-to-use console, wearable remote transmitters, and wide range of detection accessories, AmberSelect provides the ultimate lifestyle support solution for the high-end market. It incorporates an advanced home safety and intrusion alarm with a full-featured activity support system – so that emergency response, family contacts, and health care providers are reachable at the press of a button. The comprehensive range of AmberSelect also provides personal safety, including safety threat detection, such as smoke, floods, carbon monoxide (CO), medication reminders, and inactivity and fall monitoring.
AmberSelect Features:
Ultra-modern and streamlined design fits any décor Programmable inactivity monitoring and fall monitoring via a wearable detector Comprehensive environmental safety detection - including, smoke, flood, carbon monoxide (CO), and intrusion monitoring Emergency call initiation and pick-up of incoming calls using wearable
remote transmitters Built-in, two-way speakerphone – with high-volume setting and high-sensitivity microphone Up to 16 customizable reminders (voice messages and on the LCD display) Large LCD screen with unlimited language options, and time and date display Support for up to 29 (for private homes) or 255 (for group living facilities)
wireless transmitters Local and remote programming via PC or telephone line Comprehensive anti-failure protection features – including power failure and low or missing battery alerts, 24-hour backup battery, and programmable periodic test
AmberClassic
AmberClassicEmergency response and personal safety monitoring system
Amber®Classic provides a comprehensive and highly-flexible solution to enhance the safety and comfort of aging seniors and others living at home who need ongoing health and safety reassurance. The AmberClassic enables such people to live securely and comfortably at home while relieving their families of worry.
AmberClassic supports independent living with a full array of home and personal safety alarms to detect dangers such as carbon monoxide (CO), smoke, floods and intrusions, as well as falls and unusual inactivity that may indicate a problem.
Alerts and a large emergency button provide immediate connection to an emergency response service or designated personal contact.
AmberClassic Features:
Complete danger detection - including smoke, floods, and carbon monoxide (CO) One-button emergency dialing to a medical center or private number Fall monitoring via wearable detector Customizable inactivity monitoring – reports on deviations from normal daily activities Remote emergency button activation Built-in, two-way, high-volume speakerphone with:
Emergency call initiation and pick-up of incoming calls using wearable remote transmitters High volume setting – ideal for hard-of-hearing High-sensitivity microphone - enables a frail voice to be heard even from afar Up to 16 customizable voice and display reminders Intrusion monitoring option Easy remote programming through a telephone line Large LCD screen with unlimited language options Support for up to 29 (for private homes) or 255 (for group living facilities)
wireless transmitters Fully upgradeable software - supports additional languages and capabilities Power failure, low or missing battery alerts, and 24-hour backup battery Programmable periodic test Low-battery indication for pendants
AmberBasic
AmberBasicPersonal Emergency Response System
Amber®Basic is a convenient and highly affordable personal emergency response system (PERS) designed to give individuals coping with aging and ongoing health problems the opportunity to continue living in their own familiar environment. At the same time, the AmberBasic provides peace of mind to them and their families by opening up a direct and immediate channel to assistance.
AmberBasic fully addresses emergency response needs by providing an emergency calling function with built-in two-way voice functionality and a speakerphone that can be directed to a central station or private telephone. In addition, the AmberBasic further facilitates independence by providing daily activity reminders and inactivity monitoring. This highly reliable system also includes multiple functions to guarantee that it remains active at all times, so that help is never more than a button-click away.
AmberBasic Features:
Emergency calling to a central station or private telephone Built-in two-way voice and speakerphone Supports up to 28 transmitters Wristband or pendant-style transmitter with LED Inactivity monitoring Up to four reminders of key information Log file supports saving of up to 250 events 24-hour rechargeable backup battery Power failure and low battery alerts Programmable periodic test for main unit and transmitters Pendant battery supervision
CONTROL KEYFOBS
One-way Keyfob MCT-234
4-button miniature wireless keyfob transmitter designed for easy arming and disarming.more
Two-way Keyfob MCT-237
6-button miniature wireless two-way keyfob with an icon-based LCD display designed for arming and disarming.more
Conrol Keyfobs MCT-101/102/104
One, two and four button hand-held PowerCode wireless transmitters designed for emergency and control applications.
KEYPADS & ARMING DEVICES
Remote Commander MCM-140
Universal wireless portable remote control unit for PowerMax home security systems.
Two-way Keypad MKP-150/151
Two-way wireless keypad for PowerMax home security systems, provides all of the controls, notifications, indications and voice prompts of the control panel.
One-way Keyfob MCT-234
4-button miniature wireless keyfob transmitter designed for easy arming and disarming.
Two-way Keyfob MCT-237
6-button miniature wireless two-way keyfob with an icon-based LCD display designed for arming and disarming.
INTRUSION DETECTORS
Motion Detector Next+ PIR MCW
Wireless digital PIR detector for home, office or commercial use.
Pet-immune Detector Next+ K9-85 MCW
Pet-tolerant wireless digital PIR detector; prevents false alarms caused by pets weighting up to 38kg (85lb).
Motion Mirror Detector TOWER-40 MCW
Premium wireless PIR detector with extended range and coverage area; ideal for commercial installations and large residences.
Motion Curtain Detector Clip MCW
Industry's smallest and most elegant wireless curtain-type PIR detector designed for the protection of doors, windows and all-glass walls.
Door/Window contact MCT-302
Fully supervised PowerCode wireless magnetic contact transmitter, designed for protecting doors and windows.
Door/Window Contact MCT-320
Fully supervised, compact PowerCode door/window contact transmitter, designed primarily for protecting doors and windows.
Disc MCW
Ceiling mount PIR detector provides 360o detection for large residential rooms and light commercial facilitiesmore Glass-break Detector MCT-501
Digital glass-break wireless detector compatible with PowerMax and other Visonic PowerCode wireless systems.
Universal Transmitter MCT-100
Wireless fully supervised, two-input transmitter designed for protecting doors, windows or other objects.
Motion Detector MCPIR-3000
A fully supervised wireless PIR detector with advanced anti-collision technology.
Motion Detector K-940MCW
Pet-tolerant wireless PIR detector with advanced anti-collision technology compatible with PowerMax™, PowerCode wireless panels and receivers.
Motion Detector Discovery PIR MCW
Wireless PIR detector for professional installers and end-users alike.
Pet-immune Detector Discovery K9-80 MCW
Pet-tolerant wireless PIR detector for professional installers and end-users; prevents false alarms caused by pets weighting up to 36kg (80lb).
Motion Detector Discovery Quad MCW
Wireless digital Ouad detector successfully prevent false alarms in extremely harsh environment conditions including commercial and light industrial applications.
INTRUSION DETECTORS OUTDOOR
Outdoor Motion Detector TOWER-20AM MCW
Ground-breaking wireless outdoor mirror detector with anti-masking ; provides unparalleled alarm detection in outdoor environments.
PERSONAL EMERGENCY
A wide variety of personal emergency alert transmitters can be connected to Visonic PowerMax® home security systems . Available as wristbands, pendants and belt clip-ons, and as wall-mounted buttons, Visonic personal emergency alert transmitters go where needed and can be located in strategic places around the house.
Pendant MCT-201
Miniature pendent PowerCode wireless transmitter designed for emergency and control applications.
Waterproof Pendant MCT-201WP
Miniature pendent PowerCode wireless transmitter designed for emergency and control applications.
Pendant MCT-241
Stylish wireless waterproof pedant transmitter for emergency alert applications in wireless security alarm and emergency response systems.
Emergency Button MCT-220
Wireless emergency button for people who need to raise emergency alarm when they are not close to the control panel.
Wrist MCT-211
Miniature wristband waterproof PowerCode transmitter, designed for personal emergency signaling and other applications.
Man-down MDT-122
Microprocessor-controlled "man-down" personal emergency transmitter designed for use by guards and security officers in prisons and institutions.
Fall Detector MCT-241MD
Stylish wireless waterproof fall detector automatically triggers a call to the monitoring center for immediate help when user falls.
Twin Button MCT-124
Hand-held 4-button PowerCode wireless transmitter designed to prevent accidental activation of distress signaling.
SAFETY DETECTORS
Safety Detectors
Visonic home safety systems comprise a complete range of fully supervised wireless safety sensors for smoke, gas, CO, flood and temperature detection. All detectors work with PowerMax home security systems, creating complete and highly reliable security and safety solution for any premises. All the detectors are certified by the strictest international standards and offer easy installation and maintenance.
Smoke Detector MCT-425
Wireless photoelectric smoke detector designed for a wide range of residential and commercial applications.
Smoke Detector MCT-426
Wireless photoelectric smoke detector with longer battery life designed for a wide range of residential and commercial applications
Smoke & Heat Detector MCT-427
Wireless photoelectric smoke and heat detector with longer battery life designed for a wide range of residential and commercial applications
Natural Gas Detector MCT-441
Wireless natural gas detector provides rapid warning about leak of natural gas (Methane CH4) commonly used for cooking, home and water heating.
Carbon Monoxide Detector MCT-442
Wireless carbon monoxide (CO) detector gives early warning before CO levels become dangerous.
Flood Detector MCT-550
Highly sensitive wireless flood detector detects water at ground level.
Temperature Detector MCT-560
Wireless temperature detector issues an alert when the ambient temperature reaches a predetermined threshold.
Water Management Kit MCW-570
Complete standalone water management kit for residential properties, provides early flood detection and resolution by automatically shutting off the main water supply when water is sensed on the floor
SIRENS
Indoor Siren MCS-720
Two-way, fully-wireless indoor siren, ideal for residential and light commercial buildings, particularly where outdoor sirens are prohibited.
Outdoor Siren MCS-730
Two-way, fully-wireless outdoor siren (IP55) provides the perfect solution for home owners looking for an external siren that is both affordable and easy to install.
Indoor Hardwired Siren-10
Hardwired siren that combines low current, loud output (110db) and minimal electric current consumption - all at an affordable cost
ART PROTECTION DETECTOS
Art Protection Detector SPD-1000
Discreet and effective wireless displacement detector specially designed for protection of individual art works
REPEATERS
Repeater MCX-600
Wireless repeater that extends the communication range of PowerCode systems.
Repeater MCX-610
Advanced wireless repeater that extends the communication range of PowerCode systems.
WIRELESS RECEIVERS
Receiver MCR-304
Superheterodyne receiver designed for easy and cost-effective upgrading, enabling hard-wired control panels to operate with wireless remote devices.
Receiver MCR-308
Superheterodyne receiver designed to convert a standard hard-wired control panel into a reliable fully supervised wireless system.
BRACKETS
Bracket BR-1
A universal wall mount bracket that accommodate most of Visonic's PIR detectors.
Bracket BR-2
A universal corner mount bracket that accommodate most of the Visonic's PIR detectors.
Bracket BR-3
A universal ceiling mount bracket that accommodate most of Visonic's PIR detectors
SPEECH PROCESSORS
Speech Box
Extends the voice notifications and two-way voice communication capabilities of PowerMaxPro and PowerMaxComplete control panels.
GSM/GPRS & IP Communication
Visonic’s PowerMax home security alarm systems include cellular and IP connectivity options for broadband- and/or GSM/GPRS communications, enabling uninterrupted data transfer in case of a link failure or interferences. These options enable to install the home security system with the most suitable communication links and security backup for any premises and any customer. Additionally, you can connect the IP-enabled PowerMax system to PowerLink, Visonic’s Internet-based solution, and to the offered wireless surveillance cameras for advanced home security and control.
Because most communication modules are internal, installation and upgrades are quick and easy and they can be changed or added to the panel – even several years later – according to the evolving infrastructure.
COMMUNICATION MODULES
GSM-350 with GPRS Connectivity
Cellular communication module connects PowerMax selected versions to the central station via GPRS data channel and/or through the GSM network.
PowerLink2
Advanced Internet-based solution for home security and control. Provided as an internal module for PowerMaxExpress and PowerMaxComplete control panels
SERVERS & IP GPRS RECEIVERS
IPMP - IP Management Platform
IP receiver for all Visonic's Broadband and GSM/GPRS modules; supervises the modules and forwards all events received from them to the central station
CAMERAS
Cam3200
A wireless pan/tilt network camera with an elegant design that fits well in any home and any décor.
Cam3100
A wireless network camera with an elegant design that is suited to any home and décor.
Cam2000 WL
Gives you all the freedom of WiFi connectively. It is an ideal choice for both small and mid-sized businesses and homes.
Cam2000
Gives you all the freedom of WiFi connectively. It is an ideal choice for both small and mid-sized businesses and homes
Copyright © MPH Commercial Ltd, Company No: 7389418, All rights reserved
